Snyder Industries 1100 Gallon HDPE Vertical Liquid Storage Tank with ASTM Certification- Marked Tree

Four totes and a margin, certified

Eleven hundred gallons is four totes with a working margin, on a base that fits beside a dosing skid or in the corner of a barn. The wall is sized to ASTM D1998, the standard rotationally molded polyethylene tanks are specified to, and the certification is what says the wall was sized that way; the HDPE tank wall thickness guide explains the sizing logic and why the headspace is where a wall ages, and the freeboard sizing guide works out the usable volume once thermal expansion is accounted for. Full, it puts 13,761 pounds on a 64 inch circle at the rating, which a slab in full contact or a compacted, screeded gravel pad carries; strap it to a wall or a post, because a 64 inch base under 90 inches of liquid has a center of gravity worth respecting. The 1,100 gallon vertical tank buyers guide walks through the competing shapes at this volume; the tank sizing calculator tells you whether 1,100 gallons covers the draw, and the tank sizing guide covers days of supply.

Snyder's 1,000 to 1,200 gallon verticals

The 1830000W94303 is the same 1,100 gallons on this base an inch taller without the certification, and the 1830600N43 this same certified wall at 1,000 gallons, 9 inches lower. The 1831000C26 stands 1,000 gallons on a 60 inch base with a 2 inch fitting already in, and the 1710100N45, WV42 and 32531 lay 1,100 and 1,200 gallons down under 57 inches on an 86 inch base for a site with floor and no height.

Need a different size? Every tank in the table is in stock programs; ask for a quote on the one that fits, or call 866-418-1777.

Openings as shipped

• Access: 18 inch lid, 90 inches up; filled by hose, tote pump or truck through a dip tube, vented outside on anything that fumes.
• Outlet: specify the bulkhead fitting for the liquid when ordering; a flexible connector between the bulkhead and the hard pipe, with the valve carried on its own support.
• Service limit: 120 F / 48 C.
• Listing: ASTM certification.

The white wall shows the level in daylight; a float switch for low level protects a pump. Mount the pump below the outlet so it primes by gravity, keep the lid closed against vapor loss, and keep the tank out of direct sun where the liquid is light-sensitive. In a cold climate the outlet valve and the first run of pipe are insulated or drained; the body takes ice from the top down without harm.

In service

Well storage for a house, a barn and a garden, a rain cistern under a large roof, brine for a softener bank, treatment chemicals at a small plant that keeps certifications on file, fertilizer concentrate at a farm, and one cell of a small fire reserve of the kind the fire-water reservoir design guide describes. One liquid per tank, labeled.

Freight and unloading

The 1830500N43 ships palletized as LTL freight (NMFC 156600-01) at a class rate; the freight cost estimator turns your ZIP into a freight number; the price on this page is before freight. Two people stand 220 pounds; at 64 inches across it goes through a double door or outside. Fill it to the lid once, hold it, check the outlet fitting, and keep the certification paperwork with the project file. Keep the first delivery's paperwork with the tank; strength and date on day one is the baseline for every batch after.
