1700 Gallon Vertical Liquid Storage Tank

Where it fits

Seventeen hundred gallons is a serious water reserve for a house on a well, a fire buffer for a remote property, or a day tank for irrigation and livestock on a working farm, and this shape keeps all of it under six and a half feet tall. It goes under a lean-to or a low shed roof, beside a single storey building, or on an exposed site where a tall column would catch the wind. The trade is the pad. The 87 inch base needs a flat, level, continuous surface a little more than seven feet across; because it carries 21267 lb at full rating, a concrete pad is the right foundation, and it must be flat across its whole width or the shell will sit on a ridge. Our concrete pad sizing guide covers how to size the slab. The complete buyers guide to this tank goes deeper on siting and plumbing.

What goes in it

Water, rainwater, liquid fertilizer and the common farm and treatment chemicals that polyethylene handles are the normal loads. Keep the contents below 120 F and below 1.5 times the weight of water. Heavier liquids belong in the heavy duty version of this same shell, rated to 1.9 specific gravity, which Norwesco makes in blue and in black; the options above the price list them. For a rural fire reserve, the fire-water reservoir design guide explains where a polyethylene tank sits in a private fire protection stack. For grey water and rainwater collection, the industrial water reuse topology guide covers arranging several tanks by water quality. Size the volume with the tank sizing calculator or the tank sizing guide.

Openings and fittings

1. Outlet. A 2 inch polypropylene female NPT bulkhead fitting, factory installed low in the side wall. Your valve, camlock or hose adapter threads straight into it. Turn the tank so the outlet faces the pipe run before the first fill, and support the valve and the first length of pipe on their own so the fitting carries liquid, not hardware.
2. Manway. A 16 inch threaded vented manway on top, wide enough to fill from a hose or a pump, to drop a float in and to get a brush inside. The vent lets air out as you fill and in as you draw down; never plug it.
3. Drawing. Norwesco's drawing for this tank, linked under Technical Drawing on this page, shows the outlet height and the manway position for pipe planning.

The same shell in other versions, and sizes nearby

Same shell in black, for water that will stand a long time: the 1700 gallon black vertical tank, 40725; the colour swatches above the price switch between them. For denser liquids, the 1700 gallon blue heavy duty tank, N-40012 and the 1700 gallon black heavy duty tank, 42999 have a heavier wall. A step down on the same base is the 1550 gallon black vertical tank, 40235B; a step up is the 2000 gallon black vertical tank, 44125B, on a wider base.

Shipping and receiving

The tank ships by LTL freight, 87 inches across and 74 inches tall on the trailer and 244 lb, from Norwesco's Lancaster, Ohio or Sheldon, Iowa plant, whichever is nearer. At seven feet across it takes the full width of the trailer and a wide spot at your gate, so tell us if the delivery truck has a tight approach. The listed price is before freight; the freight cost estimator gives the lane cost to your ZIP, or request a quote for a job that needs paperwork. At the tailgate, check the part number against 40010 on the bill of lading, walk around the tank for transit damage before signing, and fill it with water the first time so any problem shows up with something harmless inside.

Questions before you order? Call 866-418-1777.
