1500 Gallon Blue Heavy Duty Vertical Liquid Storage Tank

Where it goes

A tall, narrow vertical tank for a site where floor space is tight and overhead is not: 64 inches across takes a small corner of a chemical room, a fertilizer plant or a treatment building, and the 116 inch height puts the manway above head height, so plan on a ladder or a platform for filling and inspection. It needs a flat, level, continuous pad under the whole bottom; a tank bottom that bridges a gap or sits on a crown is the usual cause of a failure at the base. Our guide to concrete pad sizing for above ground polyethylene tanks covers the pad, and the complete buyer's guide to the 1500 gallon 64 by 116 inch vertical walks through siting this footprint in detail. If the tank is filled or emptied fast by pump, read our worked examples on vent capacity for 1500 to 10000 gallon verticals.

What goes in it

Liquid fertilizer, brine, and the water treatment and industrial chemicals that polyethylene handles are the loads this rating is for; water is fine too, and where the job is a water reserve our note on fire water reservoirs for rural sites is relevant. Check every chemical against our chemical compatibility guide before it goes in, and keep the contents under 120 F. The 1.9 rating is a weight limit, 15.87 lb per gallon, not a chemical approval; a liquid can be light enough and still wrong for polyethylene. Norwesco's resin status letter and certificate documents are on file; tell us what the job requires and we will send what applies to this tank. For the volume itself, use the tank sizing calculator and the tank sizing guide.

Openings and fittings

1. Outlet. A 2 inch polypropylene female NPT bulkhead fitting, factory installed low in the side wall. Your valve threads straight into it. Support the valve and the first length of pipe on their own so the fitting carries liquid, not hardware, and leave a flexible connector between tank and pipe: a full tank settles and grows a little, and rigid pipe fights it.
2. Manway. A 16 inch threaded vented manway on top, wide enough to fill from a hose, drop a float or level sensor in, and get a hand and a brush inside.
3. Drawing. Norwesco's drawing for this tank, linked under Technical Drawing on this page, shows the outlet height and position and the manway location.

The same size in other ratings and colours

Same tank, heavy duty, in black: the 1500 gallon black heavy duty vertical storage tank. Same size at the standard 1.5 rating, for water and lighter liquids: the 1500 gallon white vertical liquid storage tank and the 1500 gallon black vertical storage tank. One size down: the 1295 gallon vertical liquid storage tank. Close in gallons, a different shape: the 1505 gallon black vertical storage tank. The swatches above the price switch between the colours and ratings of this tank.

Shipping and receiving

The tank ships LTL from the nearest of Norwesco's plants, lying on its side, 116 by 64 by 64 inches and 340 lb. The listed price is before freight; the freight cost estimator gives the lane cost to your ZIP, and for a job that needs paperwork you can request a written quote. Have a forklift or two people and a clear path ready; the tank is light for its size but awkward. At the tailgate, check the part number against 40146 on the bill of lading, roll the tank slowly and look at the whole wall and the outlet fitting for transit damage, stand it on its pad the same day, and fill it with water the first time before it carries anything heavier.

Questions before you order? Call 866-418-1777.
