9000 Gallon Vertical Liquid Storage Tank

Where it goes

This is the nine thousand for a site with ground to spare and a height limit to respect: it stands a foot and a bit over twelve feet, lower than most tanks of its capacity. It serves as a ranch water reserve, a bulk fertilizer or irrigation tank, a process water buffer and a private fire reserve; the fire water reservoir design guide covers that last job and its freeze protection, and the industrial water reuse topology guide covers rainwater and reuse trains. The pad is a circle nearly twelve feet across that must be level, continuous and carry the whole floor; full of water that floor carries 75060 lb of liquid plus the tank. Size it with the concrete pad sizing guide. The complete buyers guide to this tank goes deeper, and the tank sizing calculator and tank sizing guide settle the volume first.

Openings and fittings

1. Outlet. A 3 inch polypropylene female NPT bulkhead fitting, factory installed low in the side wall, with a 2 inch reducer in it. Connect 2 inch as supplied, or remove the reducer for the full 3 inch port and a faster drain. Decide before you buy the valve, and support the valve and the first run of pipe so the fitting carries liquid, not hardware.
2. Manway. A 22 inch threaded vented manway on top. The larger opening makes a pump drop, a float or a cleaning job easier than the smaller manway on the tanks below this size. At 146 inches up it is a stepladder reach for most people.
3. Drawing. Norwesco's drawing for this tank, linked under Technical Drawing on this page, gives the outlet height and manway position for your layout.
4. Liquid. Water and most liquid fertilizers sit inside the 1.5 specific gravity rating. For heavier liquids Norwesco makes a 1.9 rated version of this shell, listed below. Tell us what is going in and we will confirm the material suits it.

Sizes nearby

Same shell in black, which keeps light and algae out of stored water: the 9000 gallon black vertical tank 40786. Same shell rated for liquids up to 1.9 specific gravity: the 9000 gallon blue heavy duty vertical tank 43620 and the 9000 gallon black heavy duty vertical tank 43620B. One size down on a narrower, much taller shell: the 8400 gallon black vertical tank 42060B. One size up on the same footprint, taller: the 10000 gallon black heavy duty vertical tank 43130B. The colour swatches above the price switch between the versions of this tank.

Shipping and receiving

The tank ships as oversize freight (Norwesco's freight class is OVS) from Norwesco's St. Bonifacius, Minnesota plant, 141 by 141 by 146 inches and 1680 lb on the truck. A tank this wide travels on an open trailer, so plan on a forklift, a loader with forks or a crew with straps, and a clear route from the truck to the pad. The listed price is before freight; the freight cost estimator gives the lane cost to your ZIP, or request a written quote for a job that needs paperwork. At the tailgate, check the part number against 43618 on the bill of lading, look over the shell for transit damage before you sign, and fill it with water the first time before it carries anything else.

Questions before you order? Call 866-418-1777.
