Vertical Tanks

Vertical Tanks — Comprehensive Catalog

Vertical polyethylene storage tanks are the most-specified geometry across static water, chemical, and industrial process service. Our catalog spans every active SKU from Norwesco, Snyder Industries, Chem-Tainer, Enduraplas, and Bushman — from 10-gallon utility tanks to 15,500-gallon municipal-scale stationary vessels. Vertical orientation gives you the highest gallons-per-square-foot of footprint at the lowest manufacturing cost — and rotomolded one-piece polyethylene construction eliminates seams, gaskets, and corrosion failure modes that plague steel and fiberglass alternatives.

Applications

  • Bulk water storage — potable (NSF 61 models on request), irrigation, fire suppression, livestock
  • Chemical storage — acids, caustics, surfactants, oxidizers (verify resin via the Chemical Compatibility Guide)
  • Industrial process holding, batch staging, day-tank service
  • Agricultural — fertilizer, herbicide, AdBlue/DEF, water hauling supply
  • Emergency potable water reserve and CIP (Clean-In-Place) make-up

Compliance & Standards

All vertical polyethylene tanks in this catalog are rotomolded to ASTM D1998 — the industry standard governing wall-thickness vs. specific gravity, seam-free construction, and stress-crack resistance — from FDA 21 CFR 177.1520 compliant polyethylene resin. UV-12 stabilizers are co-extruded for outdoor service. NSF 61 listed models available for potable drinking water — call to specify. Maximum continuous operating temperature: 120 °F HDPE, 140 °F XLPE.

Engineering & Selection

Two specifications drive vertical tank selection: specific gravity (SG) rating and head height. Hoop stress at the tank wall is a direct function of fluid density × static head. A 1.5 SG tank can store fluids up to 1.5× water density (e.g., 30% caustic, 32% sulfuric, most fertilizers); 1.9 SG tanks handle the heaviest commercial chemistries (e.g., ferric chloride, 50% caustic, brine). Always size SG rating to your worst-case fluid. Foundations must be flat, level, full-footprint pad — never on dirt or partial support. Concrete or compacted stabilized base recommended. NPSH for downstream pumps depends on head height — coordinate with your pump vendor before final placement.

Freight & Delivery

Tanks ship LTL motor freight from the closest stocking warehouse to your delivery ZIP. Typical transit 5–10 business days. Liftgate available at delivery (per-shipment fee). Always inspect at delivery and note damage on the bill of lading before signing — that is the carrier claim trigger. Bulk-order consolidation reduces per-tank freight 25–40%. Get your LTL freight quote by ZIP, or call 866-418-1777 for same-business-day quoted pricing.

Sizing & Selection

Pick capacity first, then verify diameter and height against your installation envelope. Most vertical tanks are listed by nominal capacity; actual fill volume to outlet centerline is 90–95% of nominal. Rotomolded tolerance is ±2–3% per ASTM D1998. Need help sizing? Call our application desk at 866-418-1777.

Related Categories

Cone-Bottom Tanks Leg Tanks Open Top Tanks Chemical Compatibility Septic Tanks

  • Snyder Industries 4900 Gallon ASTM XLPE Black Heavy Duty Vertical Storage Tank

    0

    Snyder Industries

    SKU: 5480000N48

    Snyder Industries 4900 Gallon ASTM XLPE Black Heavy Duty Vertical Storage Tank

    MSRP: $23,382.00
    $22,860.00
    The item has been added
  • Snyder Industries 7000 Gallon ASTM XLPE Heavy Duty Vertical Storage Tank

    0

    Snyder Industries

    SKU: 5300700N42

    Snyder Industries 7000 Gallon ASTM XLPE Heavy Duty Vertical Storage Tank

    $22,860.00
    The item has been added
  • Snyder Industries 4900 Gallon ASTM XLPE Heavy Duty Vertical Storage Tank

    0

    Snyder Industries

    SKU: 5480000N42

    Snyder Industries 4900 Gallon ASTM XLPE Heavy Duty Vertical Storage Tank

    $22,860.00
    The item has been added
  • Snyder Industries 8000 Gallon HDPE Vertical Liquid Storage Tank with ASTM Certification

    0

    Snyder Industries

    SKU: SII-5300600N43

    Snyder Industries 8000 Gallon HDPE Vertical Liquid Storage Tank with ASTM Certification

    $22,890.00
    The item has been added
  • Snyder Industries 8000 Gallon ASTM Black Vertical Storage Tank

    0

    Snyder Industries

    SKU: 5300600N49

    Snyder Industries 8000 Gallon ASTM Black Vertical Storage Tank

    $22,890.00
    The item has been added
  • Norwesco 12000 Gallon Plastic Vertical Liquid Storage Tank in Black

    0

    Norwesco

    SKU: N-43939

    Norwesco 12000 Gallon Plastic Vertical Liquid Storage Tank in Black

    $23,053.11
    The item has been added
  • Snyder Industries 8750 Gallon ASTM XLPE Black Vertical Storage Tank

    0

    Snyder Industries

    SKU: 5360100N46

    Snyder Industries 8750 Gallon ASTM XLPE Black Vertical Storage Tank

    $23,180.00
    The item has been added
  • Snyder Industries 8750 Gallon ASTM XLPE Vertical Storage Tank

    0

    Snyder Industries

    SKU: 5360100N40

    Snyder Industries 8750 Gallon ASTM XLPE Vertical Storage Tank

    $23,180.00
    The item has been added
  • Snyder Industries 10500 Gallon ASTM 1.35 SG Black Vertical Storage Tank

    0

    Snyder Industries

    SKU: 5330000N32

    Snyder Industries 10500 Gallon ASTM 1.35 SG Black Vertical Storage Tank

    $23,340.00
    The item has been added
  • Snyder Industries 10500 Gallon ASTM 1.35 SG Vertical Storage Tank

    0

    Snyder Industries

    SKU: 5330000N29

    Snyder Industries 10500 Gallon ASTM 1.35 SG Vertical Storage Tank

    $23,340.00
    The item has been added
  • Snyder Industries 10500 Gallon ASTM 1.35 SG Black Vertical Storage Tank

    0

    Snyder Industries

    SKU: 5330300N32

    Snyder Industries 10500 Gallon ASTM 1.35 SG Black Vertical Storage Tank

    $23,340.00
    The item has been added
  • Snyder Industries 10500 Gallon ASTM 1.35 SG Vertical Storage Tank

    0

    Snyder Industries

    SKU: 5330300N29

    Snyder Industries 10500 Gallon ASTM 1.35 SG Vertical Storage Tank

    $23,340.00
    The item has been added
!
